Protect cables, wires, and hoses with heavy-duty cable protector ramps built for construction sites, events, electrical and lighting installs, and both vehicle and pedestrian traffic.
From 1-channel floor covers to 5-channel ADA cable ramps and driveway curb ramps, each model handles loads from 22,000 to 110,000 lbs.
Shop Yescom USA for reliable cable protection ramps designed for contractors, event crews, warehouses, and job sites.
FAQ
What cable diameter fits inside each ramp model?
Channel sizes by model:
- ADA 5-Channel Cable Ramp: 1 3/8" x 1 3/8" per channel
- 1-Channel Cable Ramp for 2" Cables: 2 3/4" x 1 15/16"
- 2-Channel Cable Ramp: 1 9/16" x 1 3/16" per channel
- 3-Channel Cable Ramp for 2" Cables: 2 9/16" x 1 15/16" per channel
- 1-Channel Hose Protector for 3 1/8" Cables: 3 1/8" x 3 1/8"
- 3-Channel Hose Protector for 3" Cables: 3 9/16" x 2 15/16" per channel
- Driveway Curb Ramp: 2 3/16" x 1 9/16" (utility groove)
Measure your cable diameter before ordering.
What is the difference between a 1-channel and a 3-channel cable ramp?
A 1-channel ramp protects a single cable. A 3-channel ramp routes three cables side by side with full separation. The 1-Channel Cable Ramp for 2" Cables measures 39 3/8" x 10 1/4" x 2 3/8" and supports 22,000 lbs (10 tons). The 3-Channel Cable Ramp for 2" Cables is sized at 36 7/16" x 19 11/16" x 2 3/4" and handles 44,092 lbs (20 tons). Choose based on how many lines you need to route.
How do I choose the right cable protector ramp for my needs?
Choose based on your cable diameter, the number of lines you need to route, and the type of traffic crossing over the ramp.
- For cords under 2", the 1-Channel or 2-Channel Cable Ramp supports up to 22,000 lbs.
- For hoses up to 3 1/8", the 1-Channel Hose Protector for 3 1/8" Cables handles 40,000 lbs.
- For ADA pathways, the ADA 5-Channel Cable Ramp is rated for 110,000 lbs.
- For driveways with lowered cars, the Driveway Curb Ramp includes a built-in cord channel.
How does the ADA 5-Channel Cable Ramp differ from standard cable protectors?
The ADA 5-Channel Cable Ramp is a low-profile cable protector with a wheelchair-friendly slope. It measures 43 5/16" x 29 1/2" x 1 15/16" and supports 110,000 lbs (50 tons). Made entirely of rubber (not PVC/rubber like standard ramps). Five channels fit cables up to 1 3/8" each. Ideal for hospitals, loading docks, facility entrances, and outdoor venues.
Can the driveway curb ramp also protect cables and hoses?
Yes. The Driveway Curb Ramp includes a built-in cord cover with a 2 3/16" x 1 9/16" utility groove for garden hoses or extension cords. Its primary function is to provide a 2.6-inch rise for lowered cars and SUVs. It measures 48 1/4" x 15 3/4" x 2 9/16", weighs 78.3 lbs, supports 22,046 lbs (10 tons), and includes mounting hardware for concrete, gravel, or asphalt.
What is the best heavy-duty cable ramp for warehouse use?
The 3-Channel Cable Ramp for 2" Cables supports 44,092 lbs (20 tons) and routes three cable lines across busy aisles. It weighs 32.3 lbs for stable placement without fastening. For warehouses with thicker hoses up to 3", the 3-Channel Hose Protector for 3" Cables provides larger channels with 40,000 lb capacity and weighs 46 lbs.
Which cable protector is best for outdoor events and concerts?
The 3-Channel Hose Protector for 3" Cables is built for event production. It supports 40,000 lbs (20 tons) and routes power, audio, and lighting cables in three separate channels. It measures 35 7/16" x 23 5/8" x 4 5/16", weighs 46 lbs, and stays in place without anchoring. Connect unlimited units end-to-end for full venue coverage.
Are the cable protector ramps safe for pedestrian walkways?
Yes. All models include anti-slip dot grid patterns on the lid and sides, plus bright yellow lids with safety warning symbols.
The surface texture reduces water accumulation for wet-condition traction. The 2-Channel Cable Ramp has the lowest profile at 1 3/4" tall, suited for hotel lobbies, malls, and school hallways.
Do Yescom cable protector ramps provide electrical insulation?
Yes. The PVC and rubber material insulates against electric currents, even when internal wires are damaged. The ramps also resist moisture and oil. This makes them suitable for areas where live cables cross vehicle or foot traffic. The 1-Channel Cable Ramp for 2" Cables is a good entry option for single-cable setups.
Can cable protection ramps be left outdoors year-round?
Yes. All cable ramps use weather-resistant construction with moisture and oil resistance, built for outdoor and indoor use. The Driveway Curb Ramp uses 100% synthetic rubber that is crack-proof and weather-resistant. Check covers regularly in heavy-traffic areas and replace them if damaged.
Can I connect multiple cable ramps together for longer coverage?
Yes. All models use a modular design that connects end-to-end with no limit on units. This applies to the 1-Channel Cable Ramp, 2-Channel Cable Ramp, 3-Channel Cable Ramp, and ADA 5-Channel Cable Ramp. Each unit covers approximately 35" to 43" in length.
How do I install a cable protector ramp on the floor?
No tools required for basic setup. Open the hinged lid, place cables inside the channels, and close the lid.
For permanent installation, fasten through the pre-drilled holes with nails or screws (not included). Models weigh 13.2 to 48 lbs, so they stay in place for temporary use. Use on flat surfaces only.
Do cable protector ramps have an odor when new?
Some models may have an outgassing odor when first unpackaged. This is normal for PVC and rubber products. Air the ramp outdoors before using it in enclosed indoor spaces.
