Yescom Commercial Batting Cage Cable Kit, 500ft 3/16" T316 for Wood

| 5.0 Site Review
Out of stock
Arrives by Tue, Nov 24 - Fri, Nov 27 Ships free

Yescom Commercial Batting Cage Cable Kit, 500ft 3/16" T316 for Wood

$399.99
Description

Batting Cage Cable Commercial Installation Kit: Includes 500 ft of 3/16" T316 stainless steel wire rope (7x19) and a complete matched hardware pack. Rated for 2,279 lbs ultimate breaking strength, it delivers superior corrosion resistance and sag-resistant tensioning for outdoor use. Easy to install with low upkeep - ideal for baseball batting cages, golf range netting, shade sails, greenhouse trellises, and commercial rigging.

High Quality:

  • Corrosion-Resistant T316 Steel: High-nickel T316 stainless alloy cable stands up to rust in coastal outdoor locations, humid facilities, and harsh weather conditions.
  • Flexible 7x19 Construction: 7x19 structure (7 strands x 19 wires, 133 individual wires) features an ultimate breaking strength of 2,279 lbs. It stays flexible to thread smoothly through pulleys, resisting unraveling and kinking.
  • No Extra Store Runs: Includes pad eye hooks, turnbuckle hooks and eyes, pulleys, and dual-size carabiners to build complete multi-point grid setups.
  • Smooth Rope Performance: Burr-free finish protects hands during installation and lets the wire rope slide smoothly over pulley sheaves.
  • Field-Proven Applications: Ideal for baseball batting cages, backstop netting, garden fencing, shade sails, and general sports barrier rigging.

Product Details:

  • Primary Material: Premium T316 Stainless Steel (Cable), 304 Stainless Steel (Rigging Hardware), & Aluminum (Ferrules)
  • Primary Application: Batting Cage Net Suspension & Sports Barrier Rigging
  • Package Configuration: 9 Accessory Types (223 Pieces Total)
  • Commercial Specification Breakdown:
    • 3/16" Cable Wire Rope (1 Spool)
      • Dimensions: 3/16" (4.8 mm) Dia x 500 ft (152.4 m) Length
      • Structure: 7x19 Construction (7 Strands x 19 Wires, 133 Individual Wires)
      • Ultimate Breaking Strength: 2,279.2 lbs (1,036 kg) - Laboratory test force only; not working load limit (WLL)
    • M10 Turnbuckle Hook and Eye (6 Pcs)
      • Adjustable Range: Fully closed overall length: 9.45" (240 mm) to max spread: 14.17" (360 mm) (Barrel body length: 5.91" / 150 mm)
      • Thread & Body Specs: Thread Diameter: 10 mm; Body Outer Diameter: 0.63" (16 mm); Wrench Flat: 0.47" (12 mm)
      • Component Safe Working Load: 485 lbs (220 kg) static load each
    • M15 Pulley (6 Pcs)
      • Overall Size: 2.44" (62 mm) Height x 0.83" (21 mm) Width x 0.79" (20 mm) Thickness
      • Sheave & Eye Specs: Sheave Inner Width: 0.28" (7 mm); Eye Inner Dimensions: 0.45" (11.5 mm) x 0.52" (13.2 mm); Eye Ring Rod Diameter: 0.15" (3.9 mm)
    • M10 Pad Eye Hook with Screws & Anchors (6 Sets)
      • Base Plate Specs: Length: 2.36" (60 mm); Width: 1.89" (48 mm); Mounting Hole Diameter: 0.24" (6.2 mm)
      • Loop Specs: Loop Height: 1.54" (39 mm); Inner Clearance (Height from Base): 1.02" (26 mm); Inner Width: 1.02" (26 mm); Loop Rod/Stock Diameter: 0.39" (10 mm)
      • Included Hardware: Includes 24 x M5 x 40 mm self-tapping screws and 24 x 40 mm gray expansion anchors
      • Component Safe Working Load: 617 lbs (280 kg) static load each (fitting rating only; mounting capacity varies by wall substrate)
    • M5 Cable Thimble (50 Pcs)
      • Compatibility: Fits 3/16" (4.8 mm - 5 mm) Cable
      • Dimensions: Teardrop opening inner length: 0.93" (23.5 mm); Teardrop opening inner width: 0.53" (13.5 mm); Channel outer width: 0.22" (5.6 mm); Channel Edge/Material Thickness: 0.04" (1 mm)
    • M5 Aluminum Cable Ferrule (100 Pcs)
      • Compatibility: Fits 3/16" (4.8 mm) Cable (Double-Hole Figure-8 Shape)
      • Dimensions: Outer Length: 0.86" (21.9 mm); Outer Width: 0.62" (15.8 mm); Height: 0.39" (10 mm); Inner Hole Sizes: 0.47" x 0.23" (11.9 mm x 6 mm); Wall Thickness: 0.08" (2 mm)
    • M5 Cable Clamp (18 Pcs)
      • Overall Size & U-Groove: Overall Clamp Length: 0.75" (19 mm); Overall Saddle Width: 0.91" (23 mm); Inner Groove Width: 0.24" (6.1 mm); Thread Center-to-Center Spacing: 0.43" (11 mm)
      • Thread & Base Specs: Thread Diameter: 0.20" (5 mm); Saddle Base Height: 0.39" (10 mm); Combined Base & Nut Height: 0.51" (13 mm)
    • M6 Carabiner (30 Pcs)
      • Dimensions: Overall Length: 2.36" (60 mm); Gate Opening: 0.37" (9.5 mm); Rod Diameter: 0.24" (6 mm); Large Loop Outer Width: 1.18" (30 mm); Small Loop Outer Width: 0.79" (20 mm); Small Loop Inner Width: 0.35" (9 mm)
      • Component Safe Working Load: 154 lbs (70 kg) static load each
    • M8 Carabiner (6 Pcs)
      • Dimensions: Overall Length: 3.15" (80 mm); Gate Opening: 0.43" (11 mm); Rod Diameter: 0.31" (8 mm); Large Loop Outer Width: 1.57" (40 mm); Small Loop Outer Width: 1.06" (27 mm); Small Loop Inner Width: 0.47" (12 mm)
      • Component Safe Working Load: 275 lbs (125 kg) static load each

Also In The Box:

  • 1 x 500 ft 316SS Stainless Steel 3/16" Wire Rope
  • 6 x 304SS M10 Turnbuckle Hook and Eye
  • 6 x 304SS M15 Pulley
  • 6 x 304SS M10 Pad Eye Hook
  • 24 x M5 x 40 mm Self-Tapping Screws
  • 24 x 40 mm Gray Expansion Anchors
  • 50 x 304SS M5 Cable Thimble
  • 100 x M5 Aluminum Cable Ferrule
  • 18 x 304SS M5 Cable Clamp
  • 30 x 304SS M6 Carabiner
  • 6 x 304SS M8 Carabiner

Notes:

*Disclaimer: Listed breaking strength (2,279 lbs) is the cable’s ultimate lab test force, NOT working load limit (WLL). Follow local building codes and use proper safety factors. Static rigging use only. Not for lifting, hoisting or supporting human weight.

Shipping Disclaimer: Due to the size and weight of this product, it may be shipped in multiple packages. Packages may be delivered separately by the carrier.
